DMP1012UFDF Datasheet, Mosfet, DIODES

✔ DMP1012UFDF Features

0.6mm Profile
Ideal for Low Profile Applications
PCB Footprint of 4mm2
Low On-Resistance
Fast Switching Speed
Totally Lead-Free & Fully RoHS Compliant (Notes

✔ DMP1012UFDF Application

Applications
Battery Management Application
Power Management Functions
DC-DC Converters U-DFN2020-6 (

PDF File Details

DIODES manufacturer logo

Part number:

DMP1012UFDF

Manufacturer:

DIODES ↗

File Size:

354.53kb

Download:

📄 Datasheet

Description:

12v p-channel mosfet. This new generation MOSFET is designed to minimize the on-state resistance (RDS(ON)) and yet maintain superior switching performance,

📥 Download PDF (354.53kb)
