FQD2N60C Datasheet, Mosfet, Fairchild Semiconductor

FQD2N60C Features

• Mosfet
• 1.9 A, 600 V, RDS(on) = 4.7 Ω (Max.) @ VGS = 10 V, ID = 0.95 A
• Low Gate Charge (Typ. 8.5 nC)
• Low Crss (Typ. 4.3 pF)
• 100% Avalanche Tested

PDF File Details

Part number:

FQD2N60C

Manufacturer:

Fairchild Semiconductor

File Size:

0.97MB

Download:

📄 Datasheet

Description:

600v n-channel mosfet. This N-Channel enhancement mode power MOSFET is produced using Fairchild Semiconductor®’s proprietary planar stripe and DMOS technolo
