FQD5N15 Datasheet, Mosfet, Fairchild Semiconductor

FQD5N15 Features

• Mosfet
• 4.3 A, 150 V, RDS(on) = 800 mΩ (Max.) @ VGS = 10 V, ID = 2.15 A
• Low Gate Charge (Typ. 5.4 nC)
• Low Crss (Typ. 7.5 pF)
• 100% Avalanche Tested D D

PDF File Details

Part number:

FQD5N15

Manufacturer:

Fairchild Semiconductor

File Size:

911.53kb

Download:

📄 Datasheet

Description:

150v n-channel mosfet. This N-Channel enhancement mode power MOSFET is produced using Fairchild Semiconductor’s proprietary planar stripe and DMOS technolog

FQD5N15 Application

• Applications Features
• 4.3 A, 150 V, RDS(on) = 800 mΩ (Max.) @ VGS = 10 V, ID = 2.15 A
• Low Gate Charge (Typ. 5.4 nC)
