IRFW520A - Advanced Power MOSFET

Fairchild Semiconductor

📥 Download Datasheet

IRFW520A Datasheet Preview — Preview of IRFW520A PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number: IRFW520A
Manufacturer: Fairchild Semiconductor
File Size: 288.34 KB
Datasheet: IRFW520A_FairchildSemiconductor.pdf
Description: Advanced Power MOSFET

IRFW520A Product details

Features

Avalanche Rugged Technology Rugged Gate Oxide Technology www. DataSheet4U. com IRFW/I520A BVDSS = 100 V RDS(on) = 0.2 Ω ID = 9.2 A D2-PAK 2 Lower Input Capacitance Improved Gate Charge Extended Safe Operating Area 175 C Operating Temperature Lower Leakage Current : 10 µA (Max. ) @ VDS = 100V Lower RDS(ON) : 0.155 Ω (Typ. ) Ο I2-PAK 1 1 3 2 3 1. Gate 2. Drain 3. Source Absolute Maximum Ratings Symbol VDSS ID IDM VGS EAS IAR EAR dv/dt PD Characteristic Drain-to-Source Voltage Continuous Drain Cu.
