ISL9V3040P3 Datasheet - Fairchild Semiconductor

ISL9V3040P3 EcoSPARKTM 300mJ/ 400V/ N-Channel Ignition IGBT

The ISL9V3040D3S, ISL9V3040S3S, ISL9V3040P3, and ISL9V3040S3 are the next generation ignition IGBTs that offer outstanding SCIS capability in the space saving D-Pak (TO-252), as well as the industry standard D²-Pak (TO-263), and TO-262 and TO220 plastic packages. This device is intended for use in a.

ISL9V3040P3 Features

* Space saving D-Pak package availability

* SCIS Energy = 300mJ at TJ = 25oC

* Logic Level Gate Drive Package JEDEC TO-263AB D²-Pak JEDEC TO-220AB E C G Symbol COLLECTOR G E R1 GATE JEDEC TO-252AA D-Pak JEDEC TO-262AA E C G R2 G E COLLECTOR (FLANGE) EMITTER Device
