SCAN18540T Datasheet, Driver, Fairchild Semiconductor

SCAN18540T Features

• Driver s IEEE 1149.1 (JTAG) compliant s Dual output enable signals per byte s 3-STATE outputs for bus-oriented applications s 9-bit data busses for parity applications s Reduced-swing outputs

PDF File Details

Part number:

SCAN18540T

Manufacturer:

Fairchild Semiconductor

File Size:

95.70kb

Download:

📄 Datasheet

Description:

Inverting line driver. The SCAN18540T is a high speed, low-power line driver featuring separate data inputs organized into dual 9-bit bytes with byte-orient

SCAN18540T Application

• Applications s 9-bit data busses for parity applications s Reduced-swing outputs source 32 mA/sink 64 mA s Guaranteed to drive 50Ω transmission line
