HMC554 Datasheet, Mixer, Hittite Microwave Corporation

HMC554 Features

• Mixer High LO to RF Isolation: 46 dB Passive Double Balanced Topology Low Conversion Loss: 7 dB Wide IF Bandwidth: DC - 6 GHz Small Size: 0.83 x 1.12 x 0.1 mm The HMC554 is ideal for:
<

PDF File Details

Part number:

HMC554

Manufacturer:

Hittite Microwave Corporation

File Size:

321.42kb

Download:

📄 Datasheet

Description:

Gaas mmic fundamental mixer. The HMC554 is a passive double balanced mixer that can be used as an upconverter or downconverter between 11 and 20 GHz. The miniatur

HMC554 Application

• Applications Features High LO to RF Isolation: 46 dB Passive Double Balanced Topology Low Conversion Loss: 7 dB Wide IF Bandwidth: DC - 6 GHz Small
