2SA1943N - PNP Transistor

2SA1943N Description

isc Silicon PNP Power Transistor .
High Current Capability. High Power Dissipation. High Collector-Emitter Breakdown Voltage- : V(BR)CEO= -230V(Min). Complement to Type.

2SA1943N Applications

* Power amplifier applications
* Recommend for 100W high fidelity audio frequency amplifier output stage applications ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VCBO Collector-Base Voltage -230 V VCEO Collector-Emitter Voltage -230 V VEBO Emitter-Base Voltage -

📥 Download Datasheet

Preview of 2SA1943N PDF
datasheet Preview Page 2

Datasheet Details

Part number
2SA1943N
Manufacturer
INCHANGE
File Size
210.28 KB
Datasheet
2SA1943N-INCHANGE.pdf
Description
PNP Transistor
