IRL2203NS - N-Channel MOSFET

IRL2203NS Description

isc N-Channel MOSFET Transistor *.

IRL2203NS Features

* With TO-263( D2PAK ) packaging
* High speed switching
* Low gate input resistance
* Standard level gate drive
* Easy to use
* 100% avalanche tested
* Minimum Lot-to-Lot variations for robust device performance and reliable operation

IRL2203NS Applications

* Power supply
* Switching applications
* ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE VDSS Drain-Source Voltage 30 VGSS ID IDM Gate-Source Voltage Drain Current-Continuous;Tc=25℃ Tc=100℃ Drain Current-Single Pulsed ±20 116 82 400 PD Total Dissipation 180 Tj Operat

📥 Download Datasheet

Preview of IRL2203NS PDF
datasheet Preview Page 2

Datasheet Details

Part number
IRL2203NS
Manufacturer
INCHANGE
File Size
247.52 KB
Datasheet
IRL2203NS-INCHANGE.pdf
Description
N-Channel MOSFET
