IXTH180N10T N-Channel MOSFET

INCHANGE

Description

isc N-Channel MOSFET Transistor *.

📥 Download Datasheet

IXTH180N10T Datasheet Preview — Preview of IXTH180N10T PDF

Datasheet Specifications

Part number: IXTH180N10T
Manufacturer: INCHANGE
File Size: 335.46 KB
Datasheet: IXTH180N10T-INCHANGE.pdf
Description: N-Channel MOSFET

Features

* Static drain-source on-resistance: RDS(on) ≤ 6.4mΩ@VGS=10V
* Fully characterized avalanche voltage and current
* 100% avalanche tested
* Minimum Lot-to-Lot variations for robust device performance and reliable operation

Applications

* ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VDSS Drain-Source Voltage 100 V VGS Gate-Source Voltage ±20 V ID Drain Current-Continuous 180 A IDM Drain Current-Single Pulsed 450 A PD Total Dissipation @TC=25℃ 480 W Tj Operating Junction Temperature -55
