NDS63P Datasheet - INSIGNIS

NDS63P - 2M x 32 bit Synchronous DRAM

64Mb (x32) - SDR Synchronous DRAM 2M x 32 bit Synchronous DRAM (SDRAM) Overview The 64Mb SDRAM is a high-speed CMOS synchronous DRAM containing 67,108,864bits.

It is internally configured as a quad 512K x 32 DRAM with a synchronous interface (all signals are registered on the positive edge of the clock signal, CLK).

Each of the 512K x 32 bit banks is organized as 2048 rows by 256 columns by 32 bits.

Read and write accesses to the SDRAM are burst oriented; accesses start at a selected location an

NDS63P-INSIGNIS.pdf

Preview of NDS63P PDF
NDS63P Datasheet Preview Page 2 NDS63P Datasheet Preview Page 3

Datasheet Details

Part number:

NDS63P

Manufacturer:

INSIGNIS

File Size:

1.61 MB

Description:

2m x 32 bit synchronous dram.
