NDS76P Datasheet - INSIGNIS

NDS76P 8M x 16 bit Synchronous DRAM

128Mb (x16) - SDR Synchronous DRAM 8M x 16 bit Synchronous DRAM (SDRAM) Overview The 128Mb SDRAM is a high-speed CMOS synchronous DRAM containing 128 Mbits. It is internally configured as four banks of 2M word x 16 DRAM with a synchronous interface (all signals are registered on the positive edge of the clock signal, CLK). Read and write accesses to the SDRAM are burst oriented; accesses start at a selected location and continue for a programmed number of locations in a programmed sequence. Ac.

NDS76P-INSIGNIS.pdf

Preview of NDS76P PDF
NDS76P Datasheet Preview Page 2 NDS76P Datasheet Preview Page 3

Datasheet Details

Part number:

NDS76P

Manufacturer:

INSIGNIS

File Size:

1.42 MB

Description:

8m x 16 bit synchronous dram.
