NDS66P Datasheet - INSIGNIS

NDS66P - 4M x 16 bit Synchronous DRAM

64Mb (x16) - SDR Synchronous DRAM 4M x 16 bit Synchronous DRAM (SDRAM) Overview The 64Mb SDRAM is a high-speed CMOS synchronous DRAM containing 64 Mbits.

It is internally configured as 4 Banks of 1M word x 16 DRAM with a synchronous interface (all signals are registered on the positive edge of the clock signal, CLK).

Read and write accesses to the SDRAM are burst oriented; accesses start at a selected location and continue for a programmed number of locations in a programmed sequence.

Accesses

NDS66P-INSIGNIS.pdf

Preview of NDS66P PDF
NDS66P Datasheet Preview Page 2 NDS66P Datasheet Preview Page 3

Datasheet Details

Part number:

NDS66P

Manufacturer:

INSIGNIS

File Size:

1.57 MB

Description:

4m x 16 bit synchronous dram.
