Low collector-emitter saturation voltage VCE(sat).
Satisfactory operation performances at high efficiency with
the low-voltage power supply. SOT-89
4.50±0.1 1.80±0.1
123
0.48±0.1
0.53±0.1
2.50±0.1 4.00±0.1
Unit:mm 1.50 ±0.1
0.44±0.1
0.80±0.1 2.60±0.1
0.40±0.1.
Absolute Maximum Ratings Ta = 25℃
Parameter Collector-base voltage Collector-emitter voltage Emitter-base voltage Collector current Collector power dissipation Junction temperature Storage temperature
Symbol VCB.
