MRF10120 MICROWAVE POWER TRANSISTORS

MOTOROLA The RF Line SEMICONDUCTOR TECHNICAL DATA Order this document by MRF10120/D Microwave Long Pulse Power Transistor Designed for 960 1215 MHz long pulse common base amplifier applications such as JTIDS and Mode S transmitters. Guaranteed Performance @ 1.215 GHz, 36 Vdc Output Power = 120 Watts Peak Gain = 8.0 dB Min., 9.2 dB (Typ) 100% Tested for Load Mismatch at All Phase Angles with 3:1 VSWR Hermetically Sealed Industry Standard Package .
