NCEP055NH40GU - N-Channel Super Trench III Power MOSFET

NCE Power Semiconductor

NCEP055NH40GU Datasheet Preview — Preview of NCEP055NH40GU PDF

Datasheet Details

Part number	NCEP055NH40GU
Manufacturer	NCE Power Semiconductor
File Size	726.55 KB
Description	N-Channel Super Trench III Power MOSFET
Datasheet	NCEP055NH40GU-NCEPowerSemiconductor.pdf

NCEP055NH40GU Product details

Description

The NCEP055NH40GU uses Super Trench III technology that is uniquely optimized to provide the most efficient high frequency switching performance. DC/DC Converter Ideal for high-frequency switching and synchronous rectification General

Features

VDS =40V,ID =68A RDS(ON)=4.5mΩ (typical) @ VGS=10V RDS(ON)=7.7mΩ (typical) @ VGS=4.5V.
Excellent gate charge x RDS(on) product(FOM).
Very low on-resistance RDS(on).
150 °C operating temperature.
Pb-free lead plating 100% UIS TESTED! 100% ΔVds TESTED! PDFN 5X6-8L Top View Bottom View Schematic Diagram Package Marking and Ordering Information Device Marking P055NH40GU Device NCEP055NH40GU Device Package PDFN5X6-8L Reel Size Ø330mm Tape width 12mm Quantity 5000u.
