NX7002AKW Datasheet, Mosfet, NXP Semiconductors

NX7002AKW Features

• Mosfet
• Very fast switching
• Trench MOSFET technology
• ESD protected 1.3 Applications
• Relay driver
• High-speed line driver
• Low-side load

PDF File Details

Part number:

NX7002AKW

Manufacturer:

NXP ↗ Semiconductors

File Size:

198.91kb

Download:

📄 Datasheet

Description:

Mosfet. N-channel enhancement mode Field-Effect Transistor (FET) in a small SOT323 (SC-70) Surface-Mounted Device (SMD) plastic package using

NX7002AKW Application

• Applications
• Relay driver
• High-speed line driver
• Low-side loadswitch
• Switching circuits 1.4 Quick reference
