74AVC16374 Datasheet, Flip-flop, NXP

74AVC16374 Features

• Flip-flop
• Wide supply voltage range from 1.2 to 3.6 V
• Complies with JEDEC standard no. 8-1A/5/7
• CMOS low power consumption
• Input/output tolerant up to 3.6

PDF File Details

Part number:

74AVC16374

Manufacturer:

NXP ↗

File Size:

84.90kb

Download:

📄 Datasheet

Description:

16-bit edge triggered d-type flip-flop. 74AVC16374 The 74AVC16374 is a 16-bit edge triggered flip-flop featuring separate D-type inputs for each flip-flop and 3-state outp

74AVC16374 Application

• Applications The 74AVC16374 consist of 2 sections of eight edge triggered flip-flops. A clock input (CP) and an output enable (OE) are provided per
