PESD3V3S1UL - Unidirectional ESD protection diodes

Product Overview

NXP

PESD3V3S1UL Unidirectional ESD protection diodes by NXP - Datasheet Preview — Datasheet preview – PESD3V3S1UL

Datasheet Details

Part number	PESD3V3S1UL
Manufacturer	NXP
File Size	221.37 KB
Description	Unidirectional ESD protection diodes
Datasheet	PESD3V3S1UL Datasheet
Additional preview pages of the PESD3V3S1UL datasheet.

Product details

Description

Unidirectional ElectroStatic Discharge (ESD) protection diodes in a SOD882 leadless ultra small Surface Mounted Device (SMD) plastic package designed to protect one signal line from the damage caused by ESD and other transients.

Features

Ultra small SMD plastic package.
ESD protection of one line.
Max. peak pulse power: PPP = 150 W.
Low clamping voltage: VCL = 20 V.
AEC-Q101 qualified.
Ultra low leakage current: IRM < 700 nA.
ESD protection up to 30 kV.
IEC 61000-4-2; level 4 (ESD).
IEC 61000-4-5; (surge); IPP up to 15 A 1.3.
