FPD87392BXB Datasheet, (sxga/sxga+/uxga), National Semiconductor

FPD87392BXB Features

• (sxga/sxga+/uxga) n Input frequency range from 25 MHz to 85 MHz n Support display resolutions SXGA (1280x1024), SXGA+ (1400x1050) and UXGA (1600x1200) n Embedded gate array for custom panel timing n RSDS

PDF File Details

Part number:

FPD87392BXB

Manufacturer:

National Semiconductor

File Size:

1.93MB

Download:

📄 Datasheet

Description:

+3.3v tft-lcd timing controller with dual lvds inputs/dual rsds outputs for tft-lcd monitor and notebook (sxga/sxga+/uxga). The FPD87392BXB Panel Timing Controller is an integrated FPD-Link + RSDS™ + TFT-LCD Timing Controller. The logic architecture is impl
