NTBG025N065SC1 Datasheet, Mosfet, ON Semiconductor

NTBG025N065SC1 Features

• Mosfet
• Typ. RDS(on) = 19 mW @ VGS = 18 V Typ. RDS(on) = 25 mW @ VGS = 15 V
• Ultra Low Gate Charge (QG(tot) = 164 nC)
• Low Output Capacitance (Coss = 278 pF)

PDF File Details

Part number:

NTBG025N065SC1

Manufacturer:

ON Semiconductor ↗

File Size:

309.28kb

Download:

📄 Datasheet

Description:

Sic mosfet.

NTBG025N065SC1 Application

• Applications
• SMPS (Switching Mode Power Supplies)
• Solar Inverters
• UPS (Uninterruptable Power Supplies)
• Energ
