BFG540X, BFG540 - NPN 9 GHz wideband transistor

BFG540X Description

DISCRETE SEMICONDUCTORS DATA SHEET BFG540; BFG540/X; BFG540/XR NPN 9 GHz wideband transistor Product speciļ¬cation File under Discrete Semiconductors.
NPN silicon planar epitaxial transistors, intended for wideband applications in the GHz range, such as analog and digital cellular telephones, cordles.

BFG540X Features

* High power gain
* Low noise figure
* High transition frequency

BFG540X Applications

* in the GHz range, such as analog and digital cellular telephones, cordless telephones (CT1, CT2, DECT, etc. ), radar detectors, satellite TV tuners (SATV), MATV/CATV amplifiers and repeater amplifiers in fibre-optical systems. The transistors are mounted in plastic SOT143B and SOT143R packages. PINN

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: BFG540X, BFG540. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
BFG540X, BFG540
Manufacturer
Philips
File Size
312.40 KB
Datasheet
BFG540_PhilipsSemiconductors.pdf
Description
NPN 9 GHz wideband transistor
Note
This datasheet PDF includes multiple part numbers: BFG540X, BFG540.
Please refer to the document for exact specifications by model.
