PAW3502 - USB OPTICAL MOUSE SINGLE CHIP

Product Overview

PixArt

Datasheet Details

Part number	PAW3502
Manufacturer	PixArt
File Size	363.08 KB
Description	USB OPTICAL MOUSE SINGLE CHIP
Datasheet	PAW3502 Datasheet
Additional preview pages of the PAW3502 datasheet.

Product details

Description

The PAW3502 is a CMOS process optical mouse sensor single chip with USB interface that serves as a nonmechanical motion estimation engine for implementing a computer mouse.

Features

Key Specification USB interface Single power supply Power Supply Wide operating supply range 4.25V ~ 5.5V Optical motion estimation technology Interface USB Complete 2-D motion sensor Optical Lens Accurate motion estimation over a wide range of surfaces System Clock High speed motion detection up to 28 inches/sec Power saving mode during times of no Speed movement Acceleration Supports three buttons (R, M, L) and three axes (X, Y, Z) output Resolution 1:1 24.000.
