ESDA14V2-1BF3 - TVS Clamping Array

Product Overview

ST Microelectronics

📥 Download Datasheet

ESDA14V2-1BF3 TVS Clamping Array by ST Microelectronics - Datasheet Preview — Datasheet preview – ESDA14V2-1BF3

Datasheet Details

Part number	ESDA14V2-1BF3
Manufacturer	STMicroelectronics
File Size	240.74 KB
Description	TVS Clamping Array
Datasheet	ESDA14V2-1BF3 Datasheet
Additional preview pages of the ESDA14V2-1BF3 datasheet.

Product details

Description

The ESDA14V2-1BF3 is a monolithic bidirectional diode designed to protect 1 line against ESD transients.

Features

ESD Protection: IEC61000-4-2 level 4 Low leakage current Very small PCB area < 0.4 mm² 400 micron pitch Flip Chip (2 bumps) Complies with the following standards.
IEC61000-4-2 level 4.
15 kV (air discharge).
8 kV (contact discharge) Figure 1.
