STTH6006CW

HIGH FREQUENCY SECONDARY RECTIFIER

STTH6006CW Features

* COMBINES HIGHEST RECOVERY AND VOLTAGE PERFORMANCE ULTRA-FAST, SOFT AND NOISE-FREE RECOVERY INSULATED PACKAGE: ISOTOP Insulation voltage: 2500 VRMS Capacitance: < 45 pF LOW INDUCTANCE AND LOW CAPACITANCE ALLOW SIMPLIFIED LAYOUT DESCRIPTION Dual rectifiers suited for Switch Mode Power Supply and high

STTH6006CW General Description

Dual rectifiers suited for Switch Mode Power Supply and high frequency DC to DC converters. Packaged either in ISOTOP or in TO-247, this device is intended for use in low voltage, high ABSOLUTE RATINGS (limiting values, per diode) Symbol VRRM IF(RMS) IF(RMS) IF(AV) Parameter Repetitive peak reverse .

STTH6006CW Datasheet (98.63 KB)

Preview of STTH6006CW PDF

Datasheet Details

Part number:

STTH6006CW

Manufacturer:

STMicroelectronics ↗

File Size:

98.63 KB

Description:

High frequency secondary rectifier.
