SM13N50C - 500V N-Channel MOSFET

📥 Download Datasheet

SM13N50C Datasheet Preview — Preview of SM13N50C PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	SM13N50C
Manufacturer	SemiMOS
File Size	1.11 MB
Description	500V N-Channel MOSFET
Datasheet	SM13N50C-SemiMOS.pdf

SM13N50C Product details

Features

Low Intrinsic Capacitances.
Excellent Switching Characteristics.
Extended Safe Operating Area.
Unrivalled Gate Charge :Qg= 42nC (Typ. ).
BVDSS=500V,ID=13A.
RDS(on) :0.5 Ω (Max) @VG=10V.
100% Avalanche Tested 1.Gate (G) 2.Drain (D) 3.Source (S) Absolute Maximum Ratings (Ta=25℃ unless otherwise noted) Symbol VDSS ID VGS(TH) EAS IAR PD Tj Tstg TL Parameter Drain-Source Voltage Drain Current Gate Threshold Voltage Tj=25℃ Tj=100℃.
