HV2661 - Low Charge Injection 24-Channel High Voltage Analog Switch

Product Overview

Supertex

Datasheet Details

Part number	HV2661
Manufacturer	Supertex
File Size	403.54 KB
Description	Low Charge Injection 24-Channel High Voltage Analog Switch
Datasheet	HV2661 Datasheet
Additional preview pages of the HV2661 datasheet.

Product details

Description

The Supertex HV2661 is a low charge injection 24-channel high voltage analog switch integrated circuit (IC) intended for use in applications requiring high voltage switching controlled by low voltage control signals, such as medical ultrasound imaging, piezoelectric transducer driver, and printers.

Features

24-channel high voltage analog switch.
3.3 or 5.0V CMOS input logic level.
3:1 MUX-deMUX with 8 states.
20MHz data shift clock frequency.
HVCMOS technology for high performance.
Very low quiescent power dissipation, 10µA.
Low parasitic capacitance.
DC to 50MHz analog signal frequency.
-60dB typical OFF-isolation at 5.0MHz.
CMOS logic circuitry for low power.
Excellent noise immunity.
