SSM6N7002FU, Silicon N-Channel MOSFET

SSM6N7002FU TOSHIBA Field Effect Transistor Silicon N Channel MOS Type SSM6N7002FU High Speed Switching Applications Analog Switch Applications .

datasheet Preview Page 1 from Datasheet4u.com

SSM6N7002FU_ToshibaSemiconductor.pdf

SSM6N7002FU Datasheet Preview — Preview of SSM6N7002FU PDF

Datasheet Details

Part number:

SSM6N7002FU

Manufacturer:

Toshiba ↗ Semiconductor

File Size:

209.98 KB

Description:

Silicon N-Channel MOSFET

Applications

* Analog Switch Applications
* Small package
* Low ON resistance : Ron = 3.3 Ω (max) (@VGS = 4.5 V) : Ron = 3.2 Ω (max) (@VGS = 5 V) : Ron = 3.0 Ω (max) (@VGS = 10 V) Absolute Maximum Ratings (Ta = 25°C) (Q1, Q2 Common) Unit: mm Characteristics Symbol Rating Unit Drain-Source vol
