TPCA8105 Datasheet - Toshiba Semiconductor

TPCA8105 Silicon P-Channel MOSFET

TPCA8105 TOSHIBA Field Effect Transistor Silicon P-Channel MOS Type (U-MOS III) TPCA8105 Notebook PC Applications Portable Equipment Applications Small footprint due to compact and slim package Low drain-source ON-resistance : RDS (ON) = 23 mΩ (typ.) (VGS = 4.5V） High forward transfer admittance :|Yfs| = 14 S (typ.) Low leakage current : IDSS = 10 μA (VDS = 12 V) Enhancement mode : Vth = 0.5 to 1.2 V.

TPCA8105 Datasheet (250.70 KB)

Preview of TPCA8105 PDF
TPCA8105 Datasheet Preview Page 2 TPCA8105 Datasheet Preview Page 3

Datasheet Details

Part number:

TPCA8105

Manufacturer:

Toshiba ↗ Semiconductor

File Size:

250.70 KB

Description:

Silicon p-channel mosfet.
