V40100PGW - Dual High-Voltage Trench MOS Barrier Schottky Rectifier

Vishay

Datasheet Details

Part number	V40100PGW
Manufacturer	Vishay ↗
File Size	82.27 KB
Description	Dual High-Voltage Trench MOS Barrier Schottky Rectifier
Datasheet	V40100PGW-Vishay.pdf

Trench MOS Schottky technology.
Low forward voltage drop, low power losses.
High efficiency operation.
Solder dip 275 °C max. 10 s, per JESD 22-B106.
Material categorization: For definitions of compliance please see www. vishay. com/doc?99912 TO-3PW PIN 1 PIN 3 PIN 2 CASE.
