WST2028 - N-Channel MOSFET

Winsok

WST2028 Datasheet Preview — Preview of WST2028 PDF

Datasheet Details

Part number	WST2028
Manufacturer	Winsok
File Size	1.04 MB
Description	N-Channel MOSFET
Datasheet	WST2028-Winsok.pdf

WST2028 Product details

Description

The WST2028 is the highest performance trench N-ch MOSFET with extreme high cell density , which provide excellent RDSON and gate charge for most of the small power switching and load switch applications.

Features

z Advanced high cell density Trench technology z Super Low Gate Charge z Excellent Cdv/dt effect decline z Green Device Available WST2028 N-Channel MOSFET Product Summery BVDSS 20V RDSON 50mΩ ID 2.1A.
