2SD1367
Features
- Low frequency power amplifier
- plementary to 2SB1001
1.70 0.1
0.42 0.1
0.46 0.1
- Absolute Maximum Ratings Ta = 25℃
Parameter Collector
- Base Voltage Collector
- Emitter Voltage Emitter
- Base Voltage Collector Current
- Continuous Collector Current
- Pulse (Note.1) Collector Power Dissipation Junction Temperature Storage Temperature Range Note.1:PW ≤ 10 ms, Duty cycle ≤ 20%.
Symbol VCBO VCEO VEBO IC ICP PC TJ Tstg
Rating 20 16 6 2 3 1 150
-55 to 150
- Electrical Characteristics Ta = 25℃
Parameter Collector- base breakdown voltage Collector- emitter breakdown voltage Emitter
- base breakdown voltage Collector-base cut-off current Emitter cut-off current Collector-emitter saturation voltage Base
- emitter saturation voltage DC current gain Collector output capacitance Transition frequency
Symbol
Test Conditions
VCBO Ic= 100 u A， IE= 0
VCEO Ic= 1 m A，RBE= ∞
VEBO IE= 100 u A， IC= 0
ICBO VCB= 16 V , IE= 0
IEBO VEB= 5V , IC=0
VCE(sat) IC=1 A, IB=100m A
VBE(sat)...
