Description
The plerowTM ALN-series is the compactly designed surface-mount module for the use of the LNA with or without the following gain blocks in the infrastructure equipment of the mobile wireless (CDMA, GSM, PCS, PHS, WCDMA, DMB, WLAN, WiBro, WiMAX), GPS, satellite communication terminals, CATV and so on.
Features
- S21 = 35.2 dB @ 200 MHz = 34.8 dB @ 215 MHz.
- NF of 0.8 dB over Frequency.
- Unconditionally Stable.
- Single 5V Supply.
- High OIP3 @ Low Current
Specifications (in Production)
Typ. @ T = 25°C, Vs = 5 V, Freq. = 207 MHz, Zo. sys = 50 ohm
Parameter Frequency Range Gain Gain Flatness Noise Figure (NF) Output IP3 S11 / S22
(1) (2)
Unit MHz dB dB dB dBm DB dBm
Specifications Min 200 34 35 ± 0.2 0.8 36 20 37 -20 / -20 21 160 5 50 C. W 23 ~ 25 (before fail) Surface Mount Type, 13.
