AFN1012 Datasheet, Mosfet, Alfa-MOS

AFN1012 Features

• Mosfet 20V/0.6A,RDS(ON)=360mΩ@VGS=4.5V 20V/0.5A,RDS(ON)=420mΩ@VGS=2.5V 20V/0.4A,RDS(ON)=560mΩ@VGS=1.8V Low Offset (Error) Voltage Low-Voltage Operation High-Speed Circuits Low Battery Voltage

PDF File Details

Part number:

AFN1012

Manufacturer:

Alfa-MOS

File Size:

585.20kb

Download:

📄 Datasheet

Description:

N-channel mosfet. AFN1012, N-Channel enhancement mode MOSFET, uses Advanced Trench Technology to provide excellent RDS(ON), low gate charge. These devi

AFN1012 Application

• Applications Pin Description ( SOT-523 ) AFN1012 20V N-Channel Enhancement Mode MOSFET Features 20V/0.6A,RDS(ON)=360mΩ@VGS=4.5V 20V/0.5A,RDS(ON)=4
