ASM5I23S05A Datasheet, Buffer, Alliance Semiconductor

ASM5I23S05A Features

• Buffer
• 10 MHz to 133- MHz operating range, compatible with CPU and PCI bus frequencies. Zero input - output propagation delay. Multiple low-skew outputs.

PDF File Details

Part number:

ASM5I23S05A

Manufacturer:

Alliance Semiconductor

File Size:

245.64kb

Download:

📄 Datasheet

Description:

(asm5i23s05a / asm5i23s09a) 3.3v spreadtrak zero delay buffer. ASM5P23S09A is a versatile, 3.3V zero-delay buffer designed to distribute high-speed clocks with Spread Spectrum capability. It is av

ASM5I23S05A Application

• Applications requiring zero input-output delay, all outputs, including CLKOUT, must be equally loaded. Even if CLKOUT is not used, it must have a ca
