BCT3258

8 Channel Constant Current LED Driver

BCT3258 Features

* Low 50mV Dropout at 20mA

BCT3258 General Description

The BCT3258 is a high performance constant current white LED driver. The BCT3258 uses an internal resistor to set the bias current for 8 LEDs, which are matched to 3%. The BCT3258's advantages over ballast resistors include much lower bias variation with supply voltage variation, significantly lower.

BCT3258 Datasheet (337.86 KB)

Preview of BCT3258 PDF

Datasheet Details

Part number:

BCT3258

Manufacturer:

BROADCHIP

File Size:

337.86 KB

Description:

8 channel constant current led driver.
