PE7165G Datasheet, Mosfet, ChipSourceTek

PE7165G Features

• Mosfet
• VDS = -18V, ID = -65A RDS(ON) < 4mΩ @ VGS=-4.5V RDS(ON) < 5.6mΩ @ VGS=-2.5V Schematic diagram
• High Power and current handing capability
• Lead free produc

PDF File Details

Part number:

PE7165G

Manufacturer:

ChipSourceTek

File Size:

1.02MB

Download:

📄 Datasheet

Description:

P-channel enhancement mode power mosfet. The PE7165G uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of app

PE7165G Application

• Applications PE7165G General Features
• VDS = -18V, ID = -65A RDS(ON) < 4mΩ @ VGS=-4.5V RDS(ON) < 5.6mΩ @ VGS=-2.5V Schematic diagram <
