PE8250M N-Channel Enhancement Mode Power MOSFET

📥 Download Datasheet Datasheet Preview Page 1

Description

N-Channel Enhancement Mode Power MOSFET .
The PE8250M uses advanced trench technology to provide excellent RDS(ON) and low gate charge.

📥 Download Datasheet

Preview of PE8250M PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Specifications

Part number
PE8250M
Manufacturer
ChipSourceTek
File Size
772.37 KB
Datasheet
PE8250M-ChipSourceTek.pdf
Description
N-Channel Enhancement Mode Power MOSFET

Features

* VDS = 18V, ID = 50A Schematic diagram RDS(ON) < 4.2mΩ @ VGS=4.5V RDS(ON) < 6mΩ @ VGS=2.5V RDS(ON) < 10mΩ @ VGS=1.8V ESD Rating: 4000V HBM
* High Power and current handing capability
* Lead free product is acquired
