of Read and Write modes.
The input/output pins (I/O0 *I/O15) are placed in a high-impedance state when the device is deselected (CE HIGH), the outputs are disabled (OE HIGH), the BHE and BLE are disabled (BHE, BLE HIGH), or during a Write operation (CE LOW, and WE LOW).
The CY7C1041CV33 is av
CY7C1041CV33 Features
* Pin equivalent to CY7C1041BV33
* High speed
* tAA = 10 ns
* Low active power
* 324 mW (max.)
* 2.0V data retention
* Automatic power-down when deselected
* TTL-compatible inputs and outputs
* Easy memory expansion with CE and
Datasheet Details
CY7C1041CV33, CY7
Cypress Semiconductor
226.39 KB
256k x 16 static ram.
This datasheet PDF includes multiple part numbers: CY7C1041CV33, CY7.
Please refer to the document for exact specifications by model.
