ES7134 192 KHz Stereo D/A Converter

The ES7134 is a low cost 8-pin stereo digital to analog converter. The ES7134 can accept I²S serial audio data format up to 24-bit word length. The device uses advanced multi-bit ∆-∑ modulation technique to convert data into two channel analog outputs. The multi-bit ∆-∑ modulator makes the device wi.

ES7134 Features

* z z z z z 95 dB dynamic range -85 dB THD+N Up to 200 kHz sampling frequency I2S audio data format, 16-24 bits Single power supply 4.5V to 5.5V APPLICATIONS z z z z DVD players Portable audio players Set top boxes Digital TVs ORDERING INFORMATION ES7134 -40°C ~ +85°C SOIC-8 BLOCK DIAGRAM SDATA SC
