Description
These N-Channel enhancement mode power field effect transistors are produced using Fairchild’s proprietary, planar, DMOS technology..
Features
- 1.7A, 400V, RDS(on) = 3.4Ω @VGS = 10 V Low gate charge ( typical 7.7 nC) Low Crss ( typical 6.0 pF) Fast switching 100% avalanche tested Improved dv/dt capability
D D
!.
- ◀
▲.
- G! G S
D-PAK
IRFR Series
I-PAK
G D S
IRFU Series
!
S
Absolute Maximum Ratings
Symbol VDSS ID IDM VGSS EAS IAR EAR dv/dt PD
TC = 25°C unless otherwise noted
Parameter Drain-Source Voltage - Continuous (TC = 25°C) Drain Current - Continuous.
