RF1S40N10SM - 40A/ 100V/ 0.040 Ohm/ N-Channel Power MOSFETs

Fairchild Semiconductor

Datasheet Details

Part number	RF1S40N10SM
Manufacturer	Fairchild ↗ Semiconductor
File Size	371.85 KB
Description	40A/ 100V/ 0.040 Ohm/ N-Channel Power MOSFETs
Datasheet	RF1S40N10SM_FairchildSemiconductor.pdf

40A, 100V.
rDS(ON) = 0.040Ω.
UIS Rating Curve.
SOA is Power Dissipation Limited.
175oC Operating Temperature.
Related Literature - TB334 “Guidelines for Soldering Surface Mount Components to PC Boards” Symbol D Ordering Information PART NUMBER RFG40N10 RFP40N10 RF1S40N10 RF1S40N10SM.
