Part number:
HM4P10R
Manufacturer:
H&M Semiconductor
File Size:
1.13 MB
Description:
-100v p-channel enhancement mode mosfet.
Datasheet Details
HM4P10R Features
* VDS = -100V ID =-4.0 A RDS(ON) < 210mΩ @ VGS=10V Application Battery protection Load switch Uninterruptible power supply HM4P10R Marking and pin assignment Package Marking and Ordering Information Product ID Pack Marking HM4P10R SOT-223 HM4P10R Absolute Maximum Ratings (TC=25℃unless oth
Datasheet Details
HM4P10R
H&M Semiconductor
1.13 MB
-100v p-channel enhancement mode mosfet.
