UTC1062

Low Voltage Telephone Transmission Circuit

Hangzhou Silan Microelectronics

UTC1062 Features

* Low d.c. line voltage; operates down to 1.6V (excluding polarity guard)

* Voltage regulator with adjustment static resistance

* Provides supply with limited current for external circuitry

* Symmetrical high-impedance inputs (64k Ω for dynamic, magnetic or piezoelectric microphones

UTC1062 General Description

LI NEAR I NTEGRATED CI RCUI T The UTC1062 is a bipolar integrated circuit performing all speech and line interface function required in the fully electronic telephone sets. It performs electronic switching between dialing speech. The circuit is able to operate down to d.c. line voltage of 1.6v (wi.

UTC1062 Datasheet (285.77 KB)

UTC1062 Datasheet Preview — Preview of UTC1062 PDF

Datasheet Details

Part number:

UTC1062

Manufacturer:

Hangzhou Silan Microelectronics

File Size:

285.77 KB

Description:

Low voltage telephone transmission circuit.
