UTC1062A Datasheet - Hangzhou Silan Microelectronics

Low Voltage Telephone Transmission Circuit

UTC1062A Features

* Low d.c. line voltage; operates down to 1.6V (excluding polarity guard)

* Voltage regulator with adjustment static resistance

* Provides supply with limited current for external circuitry

* Symmetrical high-impedance inputs (64k Ω for dynamic, magnetic or piezoelectric microphones

UTC1062A General Description

The UTC1062A is a bipolar integrated circuit per- forming all speech and line interface function required in the fully electronic telephone sets. It performs electronic switching between dialing speech. The circuit is able to operate down to d.c. line voltage of 1.6v (with reduced performance) to fa.

UTC1062A Datasheet (286.30 KB)

UTC1062A Datasheet Preview — Preview of UTC1062A PDF

Datasheet Details

Part number:

UTC1062A

Manufacturer:

Hangzhou Silan Microelectronics

File Size:

286.30 KB

Description:

Low voltage telephone transmission circuit.
