Part number:
BB301
Manufacturer:
Hitachi
File Size:
46.17 KB
Description:
Build in biasing circuit mos fet ic uhf rf amplifier.
* Build in Biasing Circuit; To reduce using parts cost & PC board space.
* Low noise characteristics; (NF = 1.3 dB typ. at f = 200 MHz)
* Withstanding to ESD; Build in ESD absorbing diode . Withstand up to 200 V at C = 200 pF, Rs = 0 conditions. Outline CMPAK
* 4 2 3
BB301
Hitachi
46.17 KB
Build in biasing circuit mos fet ic uhf rf amplifier.
