2SD198 - NPN Transistor

2SD198 Description

isc Silicon NPN Power Transistor isc Product Specification 2SD198 .
High Collector-Emitter Breakdown Voltage- : V(BR)CEO= 300V(Min). Excellent Safe Operating Area. Fast Switching Speed. With TO-3 Packa.

2SD198 Applications

* Voltage regulator.
* Switching mode power supply.
* Inverters . Absolute maximum ratings(Ta=25℃) SYMBOL PARAMETER VCBO Collector-Base Voltage VALUE UNIT 300 V VCEO Collector-Emitter Voltage 300 V VEBO Emitter-Base Voltage 6 V IC Collector Current-Continuous 1 A ICM C

📥 Download Datasheet

Preview of 2SD198 PDF
datasheet Preview Page 2

Datasheet Details

Part number
2SD198
Manufacturer
INCHANGE
File Size
175.67 KB
Datasheet
2SD198-INCHANGE.pdf
Description
NPN Transistor
