JANSR2N7470T1 Datasheet - International Rectifier

JANSR2N7470T1 RADIATION HARDENED POWER MOSFET

PD-95838C IRHMS57064 RADIATION HARDENED JANSR2N7470T1 POWER MOSFET 60V, N-CHANNEL THRU-HOLE (Low-Ohmic TO-254AA) Product Summary REF: MIL-PRF-19500/698 5 TECHNOLOGY ™ Part Number Radiation Level RDS(on) ID QPL Part Number IRHMS57064 100K Rads (Si) 0.0066Ω 45A JANSR2N7470T1 IRHMS53064 300K Rads (Si) 0.0066Ω 45A JANSF2N7470T1 IRHMS54064 500K Rads (Si) 0.0066Ω 45A JANSG2N7470T1 IRHMS58064 1000K Rads (Si) 0.0066Ω 45A JANSH2N7470T1 Low-Ohmic TO-254AA International Re.

JANSR2N7470T1 Features

* n Low RDS(on) n Fast Switching n Single Event Effect (SEE) Hardened n Low Total Gate Charge n Simple Drive Requirements n Ease of Paralleling n Hermetically Sealed n Ceramic Eyelets n Electrically Isolated n Light Weight Absolute Maximum Ratings Pre-Irradiation ID @ VGS = 12V, TC = 25°C ID @ VGS

JANSR2N7470T1-InternationalRectifier.pdf

Preview of JANSR2N7470T1 PDF
JANSR2N7470T1 Datasheet Preview Page 2 JANSR2N7470T1 Datasheet Preview Page 3

Datasheet Details

Part number:

JANSR2N7470T1

Manufacturer:

International Rectifier

File Size:

163.74 KB

Description:

Radiation hardened power mosfet.
