HMMC-5021 Datasheet, Amplifier, Keysight

HMMC-5021 Features

• Amplifier
    –
    – Wide-frequency range: 2 to 26.5 GHz
    –
    – High gain: 9.5 dB
    –
    – Gain flatness: ±0.75 dB

PDF File Details

Part number:

HMMC-5021

Manufacturer:

Keysight

File Size:

0.96MB

Download:

📄 Datasheet

Description:

Gaas mmic traveling wave amplifier. The HMMC-5021/22/26/QMMC-5002 is a broadband GaAs MMIC traveling wave amplifier designed for high gain and moderate output power ove
