NCE20P85G Datasheet, Mosfet, NCE Power Semiconductor

NCE20P85G Features

• Mosfet
• VDS =-20V,ID =-85A RDS(ON) < 2.5mΩ @ VGS=-4.5V RDS(ON) < 4mΩ @ VGS=-2.5V
• High density cell design for ultra low Rdson
• Fully characterized avalanche voltage

PDF File Details

Part number:

NCE20P85G

Manufacturer:

NCE Power Semiconductor

File Size:

316.67kb

Download:

📄 Datasheet

Description:

P-channel enhancement mode power mosfet. The NCE20P85G uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide

NCE20P85G Application

• Applications General Features
• VDS =-20V,ID =-85A RDS(ON) < 2.5mΩ @ VGS=-4.5V RDS(ON) < 4mΩ @ VGS=-2.5V
• High density cell desig
